Bridge Rectifier: A bridge rectifier converts AC (alternating current) to DC (direct current) using four diodes arranged in a bridge configuration. During both the positive and negative half cycles of AC input, the diodes conduct in pairs, allowing current to flow in the same direction through the load. This results in a full-wave rectified output with improved efficiency compared to a half-wave rectifier. #rectifier #electronics #electronicsrd #ElectronicsEducation https://youtube.com/@electron
